Westcoat CA-60 Grout Tape | 3-Pack
About
Create the look of tile with grout tape and concrete overlays
A skip trowel texture on its own reads as one continuous surface. Grout lines are what make it look like tile, and on a cementitious overlay, they're made with tape.
CA-60 goes down on the dry grout coat before the texture skip trowel coat. When the texture coat is dry and the tape comes up, the grout coat shows through as grout lines framed by raised texture, giving the surface a 3-dimensional finish that mimics tile. Tile size and grout line width are up to you, so each installation can have its own layout.
It's used in Westcoat custom finish systems such as Texture-Crete Custom and MACoat Custom on driveways, walkways, patios, courtyards, entryways, showrooms, and pool decks. In the Texture-Crete Wood Finish system, the same tape lays out decking and wood plank patterns.
Specs
Why Choose Westcoat CA-60 Grout Tape?
- Simulates tile with a 3-dimensional texture
- Reinforced, heavy-duty construction
- Adhesive back for easy layout over the grout coat
- 1/4", 3/8", and 1/2" grout line widths
- For driveways, patios, entryways, showrooms, and pool decks
Westcoat Systems Using CA-60 Grout Tape
CA-60 is the pattern tape in Westcoat's custom finish systems. It's applied over the grout coat to create tile patterns before the texture coat goes on. It's also used to lay out decking and wood plank patterns in Texture-Crete Wood Finish.
Decorative Texture Systems
- Texture-Crete Custom Finish | Optional tile pattern, applied to the grout coat before the texture skip trowel coat
- Texture-Crete Wood Finish | Board and plank lines for a decking or wood plank pattern
Waterproofing Systems
- ALX Custom Finish, ALX Pro Custom Finish, and MACoat Custom Finish | Optional tile pattern, applied to the grout coat before the texture skip trowel coat
Product Specifications for Westcoat CA-60 Grout Tape
SPECIFICATION DETAILS Product Type Reinforced, Adhesive-Backed Grout Tape Widths 1/4", 3/8", or 1/2" Package 3-Pack (3 Rolls, Same Width) Length ~55 Linear Yards per Roll, ~165 Linear Yards per 3-Pack* Applied Over Dry Grout Coat Removal Once Texture Coat Is Dry, Within 24 Hours
*Lengths are approximate. Square footage covered depends on tile or plank size and pattern layout.
How-To
Application Instruction Overview for Westcoat CA-60 Grout Tape
IMPORTANT! Before You Begin: Review the complete CA-60 Grout Tape Technical Data Sheet (TDS) and the System Specification for your custom finish system before installation. The information below is a brief overview and does not replace the manufacturer's complete application instructions.
Materials and Supplies
- Grout coat and texture coat materials for your Westcoat system
- Chalk box with white chalk
- Rounded pool trowel for the texture skip trowel coat
Step 1 – Prepare the Grout Coat
- Prepare the surface and install the grout coat as required in the System Specification
- For best results, let the grout coat dry overnight before laying out the pattern
- Make sure the grout coat is dry, clean, and free of debris
Step 2 – Lay Out the Pattern
- Decide on the tape width and tile size
- For straight lines, pre-measure the tile size and snap lines with a chalk box and white chalk
- Place the tape on the outside edge of each chalk line so the texture coat covers the chalk
Step 3 – Apply the Grout Tape
- Apply the tape to the grout coat, adding tape until the pattern is complete
- Rub the tape down very well to keep the texture coat from bleeding under it
Step 4 – Apply the Texture Coat
- Apply the texture skip trowel coat over the tape following the System Specification
Step 5 – Remove the Tape
- Remove the tape once the texture coat is dry
- For best results, do not leave the tape down longer than 24 hours
- Remove the tape before moving on to coloring options
Installation Limitations
- Do not apply to damp or wet surfaces
- For professional use only, by experienced applicators
Full instructions
See More
FAQ
Frequently Asked Questions About Westcoat CA-60 Grout Tape
How much tape is in a 3-pack?
Each 3-pack has three rolls of the same width, at about 55 linear yards per roll, for roughly 165 linear yards total. How much area that covers depends on your tile size and layout, so it helps to estimate the total length of grout lines in your pattern.
Which width should I choose?
The width sets the size of your grout lines. All three widths install the same way, so choose 1/4", 3/8", or 1/2" based on the look you want and the scale of your tile or plank layout.
Can I apply CA-60 directly to concrete?
No. CA-60 goes on the dry grout coat of a Westcoat custom finish system, before the texture skip trowel coat.
When should I remove the grout tape?
Pull the tape once the texture coat is dry. For best results, don't leave it down longer than 24 hours.
Can I use it for a wood plank pattern?
Yes. In the Texture-Crete Wood Finish system, CA-60 is used to lay out decking or wood plank patterns, with board size and spacing set to suit the job.
About
Create the look of tile with grout tape and concrete overlays
A skip trowel texture on its own reads as one continuous surface. Grout lines are what make it look like tile, and on a cementitious overlay, they're made with tape.
CA-60 goes down on the dry grout coat before the texture skip trowel coat. When the texture coat is dry and the tape comes up, the grout coat shows through as grout lines framed by raised texture, giving the surface a 3-dimensional finish that mimics tile. Tile size and grout line width are up to you, so each installation can have its own layout.
It's used in Westcoat custom finish systems such as Texture-Crete Custom and MACoat Custom on driveways, walkways, patios, courtyards, entryways, showrooms, and pool decks. In the Texture-Crete Wood Finish system, the same tape lays out decking and wood plank patterns.
Specs
Why Choose Westcoat CA-60 Grout Tape?
- Simulates tile with a 3-dimensional texture
- Reinforced, heavy-duty construction
- Adhesive back for easy layout over the grout coat
- 1/4", 3/8", and 1/2" grout line widths
- For driveways, patios, entryways, showrooms, and pool decks
Westcoat Systems Using CA-60 Grout Tape
CA-60 is the pattern tape in Westcoat's custom finish systems. It's applied over the grout coat to create tile patterns before the texture coat goes on. It's also used to lay out decking and wood plank patterns in Texture-Crete Wood Finish.
Decorative Texture Systems
- Texture-Crete Custom Finish | Optional tile pattern, applied to the grout coat before the texture skip trowel coat
- Texture-Crete Wood Finish | Board and plank lines for a decking or wood plank pattern
Waterproofing Systems
- ALX Custom Finish, ALX Pro Custom Finish, and MACoat Custom Finish | Optional tile pattern, applied to the grout coat before the texture skip trowel coat
Product Specifications for Westcoat CA-60 Grout Tape
| SPECIFICATION | DETAILS |
|---|---|
| Product Type | Reinforced, Adhesive-Backed Grout Tape |
| Widths | 1/4", 3/8", or 1/2" |
| Package | 3-Pack (3 Rolls, Same Width) |
| Length | ~55 Linear Yards per Roll, ~165 Linear Yards per 3-Pack* |
| Applied Over | Dry Grout Coat |
| Removal | Once Texture Coat Is Dry, Within 24 Hours |
*Lengths are approximate. Square footage covered depends on tile or plank size and pattern layout.
How-To
Application Instruction Overview for Westcoat CA-60 Grout Tape
IMPORTANT! Before You Begin: Review the complete CA-60 Grout Tape Technical Data Sheet (TDS) and the System Specification for your custom finish system before installation. The information below is a brief overview and does not replace the manufacturer's complete application instructions.
Materials and Supplies
- Grout coat and texture coat materials for your Westcoat system
- Chalk box with white chalk
- Rounded pool trowel for the texture skip trowel coat
Step 1 – Prepare the Grout Coat
- Prepare the surface and install the grout coat as required in the System Specification
- For best results, let the grout coat dry overnight before laying out the pattern
- Make sure the grout coat is dry, clean, and free of debris
Step 2 – Lay Out the Pattern
- Decide on the tape width and tile size
- For straight lines, pre-measure the tile size and snap lines with a chalk box and white chalk
- Place the tape on the outside edge of each chalk line so the texture coat covers the chalk
Step 3 – Apply the Grout Tape
- Apply the tape to the grout coat, adding tape until the pattern is complete
- Rub the tape down very well to keep the texture coat from bleeding under it
Step 4 – Apply the Texture Coat
- Apply the texture skip trowel coat over the tape following the System Specification
Step 5 – Remove the Tape
- Remove the tape once the texture coat is dry
- For best results, do not leave the tape down longer than 24 hours
- Remove the tape before moving on to coloring options
Installation Limitations
- Do not apply to damp or wet surfaces
- For professional use only, by experienced applicators
FAQ
Frequently Asked Questions About Westcoat CA-60 Grout Tape
How much tape is in a 3-pack?
Each 3-pack has three rolls of the same width, at about 55 linear yards per roll, for roughly 165 linear yards total. How much area that covers depends on your tile size and layout, so it helps to estimate the total length of grout lines in your pattern.
Which width should I choose?
The width sets the size of your grout lines. All three widths install the same way, so choose 1/4", 3/8", or 1/2" based on the look you want and the scale of your tile or plank layout.
Can I apply CA-60 directly to concrete?
No. CA-60 goes on the dry grout coat of a Westcoat custom finish system, before the texture skip trowel coat.
When should I remove the grout tape?
Pull the tape once the texture coat is dry. For best results, don't leave it down longer than 24 hours.
Can I use it for a wood plank pattern?
Yes. In the Texture-Crete Wood Finish system, CA-60 is used to lay out decking or wood plank patterns, with board size and spacing set to suit the job.
